Select	Download	Inquiry	Bearing NO.	Dimensions(mm)	Mounting dimensions	Loading kN	Limited Speed r/min	Prelaoding N	Axial rigidityRa N/μm	Weight Kg ≈
d	D	B	ramin	r1min	da min	Da/Db max	ra max	rb max	Cr	Cor	Lub.	Oil.	A(L)	B(M)	C(H)	A(L)	B(M)	C(H)
			7026C	130	200	33	2	1	142.5	187.5	2	1	144.8	190.8	6700	10000	750	2200	4400	129	187	236	3.18
			7026AC	130	200	33	2	1	142.5	187.5	2	1	136.8	181	6000	9000	1200	3600	7200	346	485	610	3.18
			7028C	140	210	33	2	1	152.5	197.5	2	1	148.7	202.6	6000	9000	800	2400	4800	134	194	264	3.37
			7028AC	140	210	33	2	1	152.5	197.5	2	1	140.4	192.2	5600	8500	1300	3900	7800	350	505	625	3.37
			7030C	150	225	35	2.1	1.1	163.5	211.5	2.1	1.1	168.4	232.5	5600	8500	900	2700	5400	143	207	262	4.1
			7030AC	150	225	35	2.1	1.1	163.5	211.5	2.1	1.1	159.1	220.6	5000	7500	1400	4200	8400	384	539	677	4.1
			7032C	160	240	38	2.1	1.1	174.5	225.5	2.1	1.1	189.1	264.5	5000	7500	1000	3000	6000	151	220	278	5.07
			7032AC	160	240	38	2.1	1.1	174.5	225.5	2.1	1.1	178.6	251	4800	7000	1600	4800	9600	4077	572	719	5.07
			7034C	170	260	42	2.1	1.1	188	242	2.1	1.1	205.6	299.3	4800	7000	1100	3300	6600	158	230	291	6.9
			7034AC	170	260	42	2.1	1.1	188	242	2.1	1.1	194.2	284	4300	6300	1750	5200	10000	427	600	754	6.9
			7036C	180	280	46	2.1	1.1	201.5	259	2.1	1.1	229.5	352.1	4500	6700	1200	3600	7200	172	250	317	9.21
			7036AC	180	280	46	2.1	1.1	201.5	259	2.1	1.1	216.8	334.1	4000	6000	1950	5800	11500	465	653	821	9.21
			7038C	190	290	46	2.1	1.1	211.5	269	2.1	1.1	235.1	370.8	4300	6300	1300	3800	7600	179	260	328	9.61
			7038AC	190	290	46	2.1	1.1	211.5	269	2.1	1.1	222.1	351.8	3800	5600	2000	6000	12000	483	678	852	9.61
			7040C	200	310	51	2.1	1.1	220	290	2.1	1.1	289.1	471.4	3800	5600	1600	4800	9600	186	270	342	12.1
			7040AC	200	310	51	2.1	1.1	220	290	2.1	1.1	273.1	447.3	3600	5300	2500	7500	75000	504	707	889	12.1
