high precision angular contact bearings factory-74 Series Angular Contact Ball Bearings-Products-Luoyang Monton Bearing Science &Technology Co.,ltd.

Select	Download	Inquiry	Designation	Principal Dimensions（mm）	Basic Load Ratings (KN)	Limited Speed (rpm)	Weight (kg) ≈
d	D	B	Cr Dynamic	Cor Static	Grease	Oil
			7406AC	30	90	23	55.6	32.7	6500	85000	0.96
			7406B	30	90	23	51.4	30.1	6000	8000	0.9
			7406C	30	90	23	57.5	33.8	6500	85000	0.96
			7407AC	35	100	25	66.4	41.9	5500	8000	1.14
			7407B	35	100	25	60.2	37.9	5000	7500	1.1
			7407C	35	100	25	66.8	41.2	5500	8000	1.14
			7408AC	40	110	27	73.7	42.1	5200	7000	1.4
			7408B	40	110	27	70.1	49.1	5000	6500	1.35
			7408C	40	110	27	80.2	53.3	5200	7000	1.4
			7409AC	45	120	29	84.5	55.1	5000	6500	1.8
			7409B	45	120	29	80.7	44.1	4500	6000	1.75
			7409C	45	120	29	93.1	60.8	5000	6500	1.8
			7410AC	50	130	31	115.8	78.3	4500	6000	2.25
			7410B	50	130	31	105.3	71.2	4000	5500	2.1
			7410C	50	130	31	119.3	81	4500	6000	2.25
			7411AC	55	140	33	121.4	84.5	4200	5600	2.75
			7411B	55	140	33	110	76.3	3800	5200	2.55
			7411C	55	140	33	125.3	87	4200	5600	2.75
			7412AC	60	150	35	131.8	95.3	3800	5200	3.4
			7412B	60	150	35	119.3	86.1	3500	4700	3.2
