Select	Download	Inquiry	Bearing Code	Dimensions(mm)	Preloading Force FV	Unloading Force KaE	Axial Rigidity Sa (N/µm)	Weight
d	D	B	smin	1smin	L	M	H	L	M	H	L	M	H	kg
			B706C.T.P4S	6	17	6	0.3	0.3	9	34	77	28	119	294	8.6	16.4	25.5	0.005
			B706E.T.P4S	6	17	6	0.3	0.3	14	60	132	42	187	429	20.9	36.5	51.4	0.005
			HCB706C.T.P4S	6	17	6	0.3	0.3	5	17	39	15	56	138	7.5	13	19.5	0.004
			HCB706E.T.P4S	6	17	6	0.3	0.3	5	28	67	15	85	211	16.5	30.3	43	0.004
			XCB706C.T.P4S	6	17	6	0.3	0.3	5	17	39	15	56	138	7.5	13	19.5	0.004
			XCB706E.T.P4S	6	17	6	0.3	0.3	5	28	67	15	85	211	16.5	30.3	43	0.004
			HS706C.T.P4S	6	17	6	0.3	0.3	5	16	31	15	52	108	6.2	10.5	14.7	0.01
			HS706E.T.P4S	6	17	6	0.3	0.3	8	25	51	23	75	157	15.3	23.8	31.6	0.01
			HC706C.T.P4S	6	17	6	0.3	0.3	4	11	21	12	35	70	6.4	9.9	13.3	0.01
			HC706E.T.P4S	6	17	6	0.3	0.3	6	18	35	18	54	107	16.2	23.7	30.6	0.01
			XC706C.T.P4S	6	17	6	0.3	0.3	4	11	21	12	35	70	6.4	9.9	13.3	0.01
			XC706E.T.P4S	6	17	6	0.3	0.3	6	18	35	18	54	107	16.2	23.7	30.6	0.01
			B707C.T.P4S	7	19	6	0.3	0.3	9	38	85	28	133	324	9.3	18.4	28.4	0.008
			B707E.T.P4S	7	19	6	0.3	0.3	16	65	145	47	202	470	23.2	40.4	57.1	0.008
			HCB707C.T.P4S	7	19	6	0.3	0.3	5	18	43	15	59	152	8.1	14.2	21.7	0.007
			HCB707E.T.P4S	7	19	6	0.3	0.3	5	30	73	15	91	228	17.8	33.5	47.5	0.007
			XCB707C.T.P4S	7	19	6	0.3	0.3	5	18	43	15	59	152	8.1	14.2	21.7	0.007
			XCB707E.T.P4S	7	19	6	0.3	0.3	5	30	73	15	91	228	17.8	33.5	47.5	0.007
			HS707C.T.P4S	7	19	6	0.3	0.3	6	17	34	18	55	118	7.1	11.4	16.2	0.01
			HS707E.T.P4S	7	19	6	0.3	0.3	9	27	54	26	81	166	17.2	26.1	34.4	0.01
